Inductive Proximity Sensor (ARD113E)

SN04-N Inductive Proximity Sensor – NPN NO

The SN04-N is a non-contact inductive proximity sensor designed to detect magnetic metals. Ideal for automation, object detection, positioning and industrial applications.

Specifications

- Model: SN04-N

- Sensor Type: Inductive Proximity Sensor

- External Dimensions: 18 × 18 × 36 mm

- Detection Distance: 4 mm

- Sensing Object: Magnetic metals

- Supply Voltage: 10–30V DC

- Output Type: NPN Normally Open (NO)

- Output Current: 300 mA

- Indicator: Red LED

- Connection: 3-wire cable

Wiring:

- Brown (BN): Positive (+V)

- Blue (BU): Ground (0V)

- Black (BK): NPN Output (NO)
