Relay, 11-pin, 12V 10A DPDT (RLY023)

Standard 11-pin octal style 10A relay with three-pole double-throw contacts.
Coil voltage 12V DC.
Contacts rated 10A at 28V DC or 10A at 240V AC or 1/6HP.
Overall size 35 x 35 x 55mm plus 14.6mm overall octal base depth.
Socket available see Order Code RLY009.

Specification:
Coil Rated Voltage: 12V DC
Current at Rated Voltage: 100mA ±10%
Coil Resistance: 50 ohms
Contact Material: Silver alloy
Must Operate Voltage: 9.6V max.
Must Release Voltage: 1.2V min.
Max. Coil Voltage: 13.2V DC
Power Consumption: 1.5W
Contact Resistance: 0.05 ohms max.
Operate Time: 20ms max.
Release Time: 15ms max.

Pinouts viewed from bottom....
